Pro-X series Pro-X10D/ Pro-X12D

Challenge them if you dare!
We are with you.

The PRO-X woofers were designed for Team Interfire Members

The Pro-X series subwoofers are the long awaited Monster woofer. Interfire has designed the Pro-X woofers with the perfect balance of Sound Quality and SPL to extract the maximum performance with clear audiophile accuracy. The 4-layer 3 inch EISV extra long voice coil will allow extreme power handling. The large surround assures maximum cone travel. When the cone has more travel the result is more bass!

"Dual voice coils-more is always better."

Features
  • Die-Cast Aluminum basket, silver painted
  • 4 layer 3 inch EISV extra long dual voice coil
  • Non-press paper cone with Santaprene Rubber surround
  • Double CONEX Spider with woven high current tinsel wires
  • Magnet: Barium Ferrite(double stacked)
  • Chrome finished Top and Bottom Plate
  • Extended & Vented Pole Piece
  • Large inverted dome dust cap
  • Nickel plated push terminal



Model Pro-X10D Pro-X12D
Diameter Size (inches) 10” 12”
Max Power Handling (watts) 1500W 2000W
RMS Continous Power Handling 700W 1000W
Nominal Impedance (Ohm) Dual 4 Ohm Dual 4 Ohm
Frequency Response (Hz) 20-1 khz 20-1 khz
Fs (Hz) 42.10 37.20
VAS (Liters) 18.50 30.60
Qts. 0.48 0.51
Qms. 5.85 5.16
Xmax (mm) 14 14
Sensitivity (dB) 84.70 87.20
Magnet Weight (oz.) 120 120
Sealed Box Size 0.39-1.0 cu.ft 0.8-1.3 cu.ft
Ported Box Size 1.0 cu.ft 1.8 cu.ft
Mounting Depth (inches) 6.49” 7.16”
Template Diameter (inches) 10.55” 11.20”
IFG series IFG-10D4/ IFG-12D4/ IFG-15D4

A perfect combination of brutal bass
with audiophile accuracy.

Sometimes the right choice is also the easiest choice.

The IFG series subwoofers are designed to be a common ground between SPL & SQ. With this approach, Interfire has set a new standard in subwoofers that appeals to most because of the broad range of installations. The IFG series subwoofers has everything you absolutely need from a subwoofer without all the hype. The newly designed EIVC voice coils are extra long, 65% longer than the previous IFB series while maintaining the ability to fire from a small enclosure. All in all, the IFG series subs provide clean, accurate bass.

Features
  • 4 Layer 2" EISV Extra Long Dual Voice Coil
  • Butyl Rubber Surround
  • Magnet Barrium Ferrite (double stacked)
  • Extended & Vented Pole Piece
  • Inverted Dome Dust Cap
  • Large Roll Heavy Duty Lead Wires woven into spider
  • Nickel Plated Push Terminals



Model IFG-10D4 IFG-12D4 IFG-15D4
Diameter Size (inches) 10” 12” 15”
Max Power Handling (watts) 1000W 1200W 1500W
RMS Continous Power Handling 500W 600W 750W
Nominal Impedance (Ohm) Dual 4 Ohm Dual 4 Ohm Dual 4 Ohm
Frequency Response (Hz) 20-1 khz 20-1 khz 20-1 khz
Fs (Hz) 34.80 29.84 25.17
VAS (Liters) 35.92 80.06 124.54
Qts. 0.52 0.58 0.55
Qms. 3.47 3.16 3.55
Xmax (mm) 14 14 18
Sensitivity (dB) 86 87 87
Magnet Weight (oz.) 80 80 100
Sealed Box Size 0.35-0.95 cu.ft 0.9-1.50 cu.ft 1.4-2.0 cu.ft
Ported Box Size 1.5 cu.ft 2.0 cu.ft 2.0 cu.ft
Mounting Depth (inches) 5.19” 5.63” 7.13”
Template Diameter (inches) 9.31” 11.19” 14.00”
MSRP $135 $150 $219
T Series
Woofers TW-124/ TW-104
Competition bass at affordable price
The TW handles up to 700 watts max, impressive for a sub in this range.
It’s optimized for use in a SMALL sealed box, the result is a terrific combination of huge output and tight, accurate sound quality.

Features
  • 4 Layer / 2" AOSV Single Voice Coil
  • Butyl Rubber Surround
  • Large Barium Ferrite Magnet
  • Extended & Vented Pole Piece
  • Large Roll Heavy Duty Lead Wires
  • Invented Dome Dust Cap
Model TW-124 TW-104
Diameter Size (inches) 10” 12”
Max Power Handling (watts) 800 w 1000 w
RMS Continuous Power Handling 250 w 350 w
Normal Impedance (Ohm) Single 4 Ohm Single 4 Ohm
Magnet Weight (oz) 50 50
Mounting Depth (inches) 5-1/6” 5-1/2”
Mounting Template Diameter (inches) 9-2/3” 11-3/5”
Fs (Hz) 35.49 27.95
VAS (Litters) 30.36 70.80
Qts 0.43 0.54
Qms 2.62 2.63
Qes 0.52 0.68
Xmax (mm) 12.0 12.0
Sensitivity (dB) 86 85
Sealed Enclosure –SPL (cu.ft) 0.31 0.73
MSRP $120 $108
